Features: Cost-effective, low operating costs, ideal for Middle East farming. Closed-loop design cuts water use by 60%. Corrosion-resistant titanium evaporator chills water to -5°C to -60°C, stabilizes environment for aquaculture (±1°C control). Supports desalination and water recycling for desert farming.
Benefits: Enhances growth efficiency, aligns with water scarcity needs.
Model OY | D140YLS | D160YLS | D180YLS | D210YLS | D240YLS | D280YLS | D300YLS D320YLS | ||
Rated Cooling Capacity | ×1000 kcal/h | 192.0 | 209.6 | 233.4 | 275.8 | 317.5 | 379.7 | 429.1 | 431.1 |
kW | 223 | 244 | 271 | 321 | 369 | 442 | 499 | 501 | |
USRT | 63.5 | 69.3 | 77.2 | 91.2 | 105.0 | 125.6 | 141.9 | 142.6 | |
Inptpower | kW | 92.4 | 99.4 | 118.6 | 134.4 | 145.1 | 171.1 | 191.6 | 205.0 |
Comp.current | 156.2 | 165.3 | 191.8 | 224.0 | 241.0 | 283.0 | 314.0 | 340.0 | |
Power Supply | 3φ-380V-50Hz | ||||||||
Protection Device | Phase Reversion Protection Phase Lack Protection Overload Current Protection Discharge AirTemperature Protection | ||||||||
Refrigerant | R22 | ||||||||
Number Of Refrigeration Circuit | 1 | ||||||||
Capacity Control | 0,50,75,100 | ||||||||
Refrigerant charge | 57 | 62 | 69 | 82 | 94 | 113 | 128 | 128 | |
Condenser | Shell-and-Tube Type | ||||||||
Mpa Water Side max Pressure | 1 | ||||||||
Dia.of pipe to Condenser | 4" | 4" | 5" | 5" | 5" | 5" | 5" | 4" | |
Cooling Water Flow m³/h | 54.3 | 59.0 | 67.1 | 78.3 | 88.4 | 105.4 | 118.8 | 121.5 | |
Condenser Water Pressure drop | 61 | 63 | 65 | 67 | 70 | 72 | 75 | 55 | |
Evaporator | Shell-and-Tube Type | ||||||||
Water Side max Pressure | 1 | ||||||||
Dia.of pipe to Evaporator(inch) | 4" | 4" | 4” | 5" | 5" | 5" | 5" | 4" | |
40%Glycol Flow Capacity m³/h | 40.6 | 44.4 | 49.4 | 58.4 | 67.2 | 80.4 | 90.8 | 91.2 | |
Evaporator Water pressure drop | 65 | 67 | 70 | 72 | 75 | 78 | 82 | 60 | |
Running noise dB(A) | 71 | 73 | 74 | 75.0 | 76.0 | 78.0 | 79.0 | 71 | |
Total Weight | 1420 | 1550 | 1670 | 1900 | 2170 | 2370 | 2460 | 1370 | |
Running Weight | 1710 | 1800 | 1980 | 2250 | 2400 | 2690 | 2910 | 1580 | |
Whether you need air-cooled chillers, heat pump units, or custom HVAC systems, we’re ready to deliver high-quality products and exceptional service.
